Welcome to cncmachiningcomponents.com
Mr. Sunil Rasal, the founder member is an Engineering Graduate, started his carrier in the year 1989 with Bharat Forge Ltd., Mundhawa, Pune. He later joined Kirloskar Oil Engines Ltd., Kirkee, Pune. |
 |
|
|
|
 |
 |
|
 |
|
| Components undertaken for machining operations CNC Lathe, CNC VMC, CNC HMC, CNC VMC etc. machining of different variety of components. |
| |
| Following machines are available on Micromech Engineering shop floor at present. |
| |
| 1) Takisawa makes VMC: Very Good VMC with following specifications. |
| |
|
Table Size (W x L): 900 mm x 410 mm. |
|
Max. Table load: 400 Kg. |
|
X Stroke 760mm, Y Stroke 415 mm, Z Stroke 415 mm. Rapid Traverse rate - 12 Mtrs. |
|
Spindle : NT - BT 40, RPM - 7000, Power - 7.5 KW. |
|
24 Tool ATC. |
|
CNC System : Fanuc 0M. |
|
| |
| 2) Cellular Concept makes HMC : Very Good HMC with following Specifications : |
| |
|
Table Size (W x L) : 610 mm x 737 mm. |
|
Max. Table load : 400 Kg. |
|
X Stroke 610 mm, Y Stroke 430 mm, Z Stroke 460 mm. Rapid Traverse rate - 20 Mtrs. |
|
Spindle : NT - BT 45, RPM - 6000, Power – 15 HP. |
|
CNC System : Fanuc 0M. |
|
| |
| 3) Mori Seiki make CNC Lathe Model TL3 : Very Good CNC Lathe with following specifications : |
| |
|
Maximum Turning Dia. : 350 mm. |
|
Maximum Distance Between Centers : 550 mm. |
|
Spindle RPM - 1000, Power - 22 KW. |
|
Hydraulic Chuck and Hydraulic Tailstock. |
|
8 Station Hydraulic turret. |
|
CNC System : Fanuc 6T. |
| |
| 4) Mitsui Seiki Make Horizontal Machining Center : Completely Re conditioned machine with Following specifications : |
| |
|
Pallet Size 630 x 630. |
|
With 4th Axis. |
|
Max Load : 1500 Kg. |
|
With ATC & APC |
|
Spindle Nose Taper BT 50. |
|
Spindle RPM 50 – 2500, Power 15 KW. |
|
CNC : Fanuc 6 M. |
| |
|
5) HMT make VMC : VTC 800, Very Good VMC with following specifications. |
|
|
|
Table Size (W x L) : 1220 mm x 635 mm. |
|
Max. Table load : 1500 Kg. |
|
X Stroke 1150mm, Y Stroke 530 mm, Z Stroke 500 mm.
Rapid Traverse rate - 12 Mtrs. |
|
Spindle : BT 50, RPM – 0-3000, Power - 7.5 KW. |
|
24 Tool ATC. |
|
CNC System : Sinumerik. |
|
|
6) IKEGAI make CNC Lathe /Turn Mill Center : |
|
Reconditioned CNC Lathe with following specifications : |
|
|
|
Maximum Turning Dia. : 850 mm. |
|
Maximum Distance Between Centers : 1450 mm. |
|
Spindle RPM : 20- 2000, Power - 30 KW, Nose taper A2-8. |
|
Hydraulic Chuck and Hydraulic Tailstock. |
|
12 station Hydraulic turret. |
|
CNC System : Fanuc 6T. |
|
|
| |
|
|
|
 |
 |
|
|
| |
|
| |
| |
|
| |
|
|
